Front Loading Dishwasher - Basket 60x50 - DIGIT Control Panel
Dishwasher equipped with an automatic water softener that adjusts its regeneration intervals based on the incoming water hardness.
The control system, managed by a simple electronic board, allows you to set and monitor rinse and drain times and temperatures, as well as the related Thermostop functions, which are essential to ensure excellent final results. Through the control panel, you can select one of the 4 wash cycles and an automatic drain cycle (with drain pump installed), easily view the tank and boiler temperatures on the display, receive messages from the Self-diagnosis system, and get notifications for Scheduled Maintenance.
Self-cleaning cycle at the end of the day. Thanks to the Thermostop function, washing and rinsing start only once the desired temperature is reached. The double electric peristaltic detergent and rinse aid dispenser, installed as standard, ensures maximum performance from every wash cycle.
Code: X84E
Brand: Compack
| Construction features |
|---|
| Structure in AISI 318 stainless steel |
| Technical sheet | |
|---|---|
| Standard power supply: 400V3N+T 50Hz | Dimensions cm 58.5x71.5x86.5h |
| No. of racks/hour - (Inlet water +55°C): Max 40 | Max glass height: 340mm |
| Max plate Ø: 370mm | Max pot height: 340mm |
| Trays: GN1/1 – 60x40 | Wash and rinse impeller: Ø18 INOX |
| Tank heating element - Tank capacity: 2.6kW – 30lt | Boiler heating element - Boiler capacity: 5.4kW – 7.3lt |
| Pump power: 1.12kW / 1.5Hp | Total power / Current: 6.52kW / 16A |
| Standard supply voltage: 400V3N+T 50Hz | Recommended water supply: +55°C |
| Recommended water hardness: 7÷10 °f | Water consumption per cycle (with recommended pressure 2 BAR): 2.0-2.5 lt |
| Adjustable detergent and rinse aid dispenser: Electric | |
